RC4558D-SMD, ic-smd, , IC

Manufacturer: Texas Instruments
Product Category: Operational Amplifiers - Op Amps
Number of Channels: 2 Channel
GBP - Gain Bandwidth Product: 3 MHz
SR - Slew Rate: 1.7 V/us
Vos - Input Offset Voltage: 6 mV
Ib - Input Bias Current: 500 nA
Supply Voltage - Max: 30 V
Supply Voltage - Min: 10 V
Operating Supply Current: 2.5 mA
Output Current per Channel: 10 mA
CMRR - Common Mode Rejection Ratio: 90 dB
en - Input Voltage Noise Density: 8 nV/sqrt Hz
Package/Case: SOIC-8
Mounting Style: SMD/SMT
Shutdown: No Shutdown
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 85 C
Series: RC4558
Packaging: Tube
Amplifier Type: General Purpose Amplifier
Brand: Texas Instruments
Dual Supply Voltage: +/- 9 V, +/- 12 V
Height: 1.58 mm
Length: 4.9 mm
Maximum Dual Supply Voltage: +/- 15 V
Minimum Dual Supply Voltage: +/- 5 V
Operating Supply Voltage: 10 V to 30 V, +/- 5 V to +/- 15 V
Product: Operational Amplifiers
Product Type: Op Amps - Operational Amplifiers
Subcategory: Amplifier ICs
Supply Type: Single, Dual
Technology: Bipolar
Voltage Gain dB: 109.54 dB
Width: 3.91 mm
Unit Weight: 72,600 mg


Šifra: 119240

Količina: 0

Kataloški brojevi:

Zamjena: MC1458D-TI(SO8), NJM4558D-JRC(DIP8), LM358D-ST(SO8), LM358D-ST(SO8), NJM4580D-JRC, NJM4580D-JRC, NJM4580E-JRC(SO8)
