FAN70/12-PF70201V1-A99-SUNON(C, 12V/0,285A/3,42W/2ŽICE(70X20),VAPO,73.06, VENTILATOR 12V, 70X70X20-VAPO

Manufacturer SUNON
Fan type DC
Fan kind axial
Supply voltage 12V DC
Operating voltage 4.5...13.8V
Fan dimensions 70x70x20mm
Power consumption 3.42W
Rated current 0.285A
Fans efficiency 73.06m3/h
Noise level 41.5dBA
Bearing type Vapo
Rotational rate/speed 4600 (±15%)rpm
Weight 80g
Current and power consumption tolerance ±15%
Min. insulation resistance 10MΩ
Fan material thermoplastic
Enclosure material thermoplastic
Insulation class A
Operating temperature -10...70°C
Leads 2 leads
Static pressure 7.11mm H2O
Cable length 300mm
Fan motor brushless DC motor
Flammability rating UL94V-0
Wire size 24AWG
Additional functions Autorestart

Šifra: 111836

Količina: 0

Kataloški brojevi: PF702001V1-A99

Zamjena:
