REL-R3N2013235-230WT-RELPOL, RELAY IND.3PDT 230VAC 10A/250VAC, RELAY, 230VAC

Manufacturer: RELPOL
Type of relay: electromagnetic
Contacts configuration: 3PDT
Rated coil voltage: 230V AC
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 10A / 24V DC
Contact current max: 20A
Switched voltage: max. 250V DC,  max. 440V AC
Relay variant: industrial
Mounting: socket
Relay series: R3N
Operating temperature: -40...55°C
Body dimensions: 27.5x21.2x35.6mm
Coil resistance: 16100Ω
Contact resistance: 100mΩ
Coil power consumption: 1.6VA
Leads: 2,2x0,5mm connectors
IP rating: IP40
Number of pins: 11
OEM number: 860406

Optional equipment:

- mechanical indicator
- test button with blocking function

Šifra: 124401

Količina: 5

Kataloški brojevi: R3N2013235230WT

Zamjena:
