REL-B6S-30-01-1.7-24VDC, RELAY 24V ZA ŠINU, , RELAY

Product Net Width:52.5 mm
Product Net Height:57.5 mm
Product Net Depth / Length:46.7 mm
Product Net Weight:0.175 kg
Number of Poles:3
Rated Operational Voltage Auxiliary Circuit: 690 V AC
Auxiliary Circuit 250 V DC
Main Circuit: 690 V AC
Main Circuit: 220 V DC
Rated Frequency (f):Control Circuit DC
Main Circuit 60 Hz
Main Circuit 50 Hz
Main Circuit: 6 kV
Rated Operational Current AC-1 (Ie) (220 / 240 V): 40 °C 20 A
Rated Operational Power AC-3 (Pe):(230 V): Three Phase 2.2 kW
Rated Operational Current AC-15 (Ie) (24 V): 4 A
Rated Operational Current DC-13 (Ie) (24 V): 2.5 A
Conventional Free-air Thermal Current (Ith): Main Circuit 20 A
Rated Control Circuit Voltage (Uc): 24 V DC
Mechanical Durability: 10000000 cycle
Minimum Switching Capacity-Auxiliary Circuit: 17 V
Auxiliary Circuit: 5 mA
Maximum Electrical Switching Frequency (AC-1): 300 cycles per hour
Power Loss at Rated Operating Conditions AC-1 per Pole: 1 W
Maximum Operating Voltage UL/CSA-Main Circuit: 600 V AC
Full Load Amps Motor Use-(115 V AC): Single Phase 5.8 A
Horsepower Rating UL/CSA-(115 V AC): Single Phase 0.25 Hp
General Use Rating UL/CSA-(300 V AC): 12 A
Connecting Capacity Main Circuit UL/CSA-Stranded: 1/2x 22-10 AWG
Connecting Capacity Auxiliary Circuit UL/CSA-Stranded: 1/2x 22-10 AWG
Tightening Torque UL/CSA-Auxiliary Circuit: 7 in·lb
Control Circuit: 7 in·lb
Main Circuit: 7 in·lb
Ambient Air Temperature-Operation: -20 ... +55 °C
Storage: -40 ... +80 °C

Šifra: 123808

Količina: 0

Kataloški brojevi:

Zamjena:
